Binder – Constant Climate Chambers – Series KBF – With Large Temperature / Humidity Range
The BINDER KBF is the specialist for unconditionally reliable stability testing and precise maintenance of constant climate conditions. From programming to documentation, this humidity test chamber meets all critical requirements.
Particularly suitable for pharmaceutical tests within a temperature and humidity range of 0 °C to +70 °C and 10% to 80% RH.
Key Features
- Homogeneous climate conditions thanks to APT.line™ technology
- Automatic water and wastewater management
- Pressure humidification with fast response times
Technical Specifications
| Model | Housing dimensions not incl. fittings and connections W x H x D | Internal dimension W x H x D | Net weight | Interior volume |
| KBF 130 | 900 x 1,050 x 710 mm | 656 x 500 x 386 mm | 126 kg | 127 L |
| KBF 260 | 930 x 1,396 x 900 mm | 656 x 695 x 575 mm | 188 kg | 262 L |
| KBF 470 | 930 x 1,951 x 900mm | 656 x 1,250 x 575 mm | 225 kg | 472 L |
| KBF 720 | 1,285 x 1,951 x 900 mm | 1,011 x 1,250 x 575 mm | 298 kg | 727 L |
| KBF 1060 | 1,285 x 1951 x 1,175 mm | 1,011 x 1,250 x 847 mm | 340 kg | 1,070 L |
| KBF 1600 | 1,795 x 1,951 x 1,175 mm | 1,521 x 1,250 x 847 mm | 438 kg | 1,610 L |
Available Models
Technical Specifications
| Max. heat compensation at 40 °C [W] | 270 |
| Temperature fluctuation [± K] | 0.1 |
|---|---|
| Temperature range [°C] | 0…70 |
| Power frequency [Hz] | 50/60 |
| Rated Voltage [V] | 200…240 |
| Unit fuse [A] | 16 |
- Temperature range: 0°C to +70°C
- Humidity range: 10% to 80% RH
- Up to 40% lower energy consumption compared to the previous model
- Cooling with climate-neutral R-600a refrigerant
- Two racks with stainless-steel telescopic rails
- Signal triangle with light-up status display (for units with a volume of 470 liters and above)
- Optional light modules for ICH photostability testing (for models 260, 470, 720)
- Optional LED light modules for plant growth (for models from 260)
Technical Specifications
| Max. heat compensation at 40 °C [W] | 410 |
| Temperature fluctuation [± K] | 0.1 |
|---|---|
| Temperature range [°C] | 0…70 |
| Power frequency [Hz] | 50/60 |
| Rated Voltage [V] | 220…240 |
| Unit fuse [A] | 16 |
- Temperature range: 0°C to +70°C
- Humidity range: 10% to 80% RH
- Up to 40% lower energy consumption compared to the previous model
- Cooling with climate-neutral R-600a refrigerant
- Two racks with stainless-steel telescopic rails
- Signal triangle with light-up status display (for units with a volume of 470 liters and above)
- Optional light modules for ICH photostability testing (for models 260, 470, 720)
- Optional LED light modules for plant growth (for models from 260)
Technical Specifications
| Max. heat compensation at 40 °C [W] | 530 |
| Temperature fluctuation [± K] | 0.1 |
|---|---|
| Temperature range [°C] | 0…70 |
| Power frequency [Hz] | 50/60 |
| Rated Voltage [V] | 200…240 |
| Unit fuse [A] | 16 |
- Temperature range: 0°C to +70°C
- Humidity range: 10% to 80% RH
- Up to 40% lower energy consumption compared to the previous model
- Cooling with climate-neutral R-600a refrigerant
- Two racks with stainless-steel telescopic rails
- Signal triangle with light-up status display (for units with a volume of 470 liters and above)
- Optional light modules for ICH photostability testing (for models 260, 470, 720)
- Optional LED light modules for plant growth (for models from 260)
Technical Specifications
| Max. heat compensation at 40 °C [W] | 640 |
| Temperature fluctuation [± K] | 0.1 |
|---|---|
| Temperature range [°C] | 0…70 |
| Power frequency [Hz] | 50/60 |
| Rated Voltage [V] | 220…240 |
| Unit fuse [A] | 16 |
- Temperature range: 0°C to +70°C
- Humidity range: 10% to 80% RH
- Up to 40% lower energy consumption compared to the previous model
- Cooling with climate-neutral R-600a refrigerant
- Two racks with stainless-steel telescopic rails
- Signal triangle with light-up status display (for units with a volume of 470 liters and above)
- Optional light modules for ICH photostability testing (for models 260, 470, 720)
- Optional LED light modules for plant growth (for models from 260)
Technical Specifications
| Max. heat compensation at 40 °C [W] | 640 |
| Temperature fluctuation [± K] | 0.1 |
|---|---|
| Temperature range [°C] | 0…70 |
| Power frequency [Hz] | 50/60 |
| Rated Voltage [V] | 220…240 |
| Unit fuse [A] | 16 |
- Temperature range: 0°C to +70°C
- Humidity range: 10% to 80% RH
- Up to 40% lower energy consumption compared to the previous model
- Cooling with climate-neutral R-600a refrigerant
- Two racks with stainless-steel telescopic rails
- Signal triangle with light-up status display (for units with a volume of 470 liters and above)
- Optional light modules for ICH photostability testing (for models 260, 470, 720)
- Optional LED light modules for plant growth (for models from 260)
Technical Specifications
| Max. heat compensation at 40 °C [W] | 640 |
| Temperature fluctuation [± K] | 0.1 |
|---|---|
| Temperature range [°C] | 0…70 |
| Power frequency [Hz] | 50/60 |
| Rated Voltage [V] | 220…240 |
| Unit fuse [A] | 16 |
- Temperature range: 0°C to +70°C
- Humidity range: 10% to 80% RH
- Up to 40% lower energy consumption compared to the previous model
- Cooling with climate-neutral R-600a refrigerant
- Two racks with stainless-steel telescopic rails
- Signal triangle with light-up status display (for units with a volume of 470 liters and above)
- Optional light modules for ICH photostability testing (for models 260, 470, 720)
- Optional LED light modules for plant growth (for models from 260)
