Zero-compromise oil-free piston compressor

Piston compressors have always presented a compelling offer: robust, low maintenance and energy efficient. However, this strong performance typically came with high noise levels and few control options. The Atlas Copco LZ eliminates this trade-off. As one of the most complete oil-free piston compressor on the market, the LZ meets all your compressed air needs and then some. The LZ oil-free piston compressors come with a full range with:

• different power options: 7- 10 hp
• pressure levels: 4 – 10 bar
• electric potential options: 230 / 400 / 460V

ZD compressor and booster combination with energysaving VSD option

Whether you need medium, high pressure or both, the ZD (VSD) high pressure screw compressor and booster delivers 100% oil-free dry air or nitrogen.

ZD range: smart air and nitrogen boosters

Our ZD (VSD) hybrid solution combines the advantages of oil-free screw technology, drum type adsorption dryer and the well-known piston booster technology. The result is in 100% oil-free dry air or nitrogen for medium- and high-pressure applications such as:

• PET Industry : blowing
• instrument air
• natural nitrogen vent capturing
• soot blower air

The ZD system is easy to install and easy to use: no complex connections or foundations are required. Z compressor and D booster can be used in parallel or separately reaching different levels of pressure ratios between 25 and 40 bar, which saves you maintenance time and costs.

Four-stage air compression with high-efficiency intercooling maximises compression efficiency. More savings can be achieved with adding Variable Speed Drive (VSD) and energy recovery.

Automan AH oil-free piston compressors (0.75-1.5 kW)

Our range of Automan AH piston compressors offers a compact, mobile and reliable source of compressed air when a smaller amount of compressed air is needed.

AH All aluminum oil-free piston compressors

Designed for a variety of applications, our AH series is the ideal choice when light weight, high mobility and smaller amounts of compressed air is sufficient.

With its state-of-the-art oil-free compressor technologies such as screw, tooth, centrifugal, reciprocating and scroll, Atlas Copco provides the right solutions for your specific needs. As oil-free compressed air is a prerequisite for many manufacturing processes, we ensure consistent oil-free air by preventing oil from entering your compressed air system.

The SF and SF+ ranges of oil-free scroll air compressors unite Atlas Copco’s vast experience and knowledge in a class-leading package. Whereas the SF range includes a standard pneumatic controller, the SF+ range boasts the high-end Elektronikon® controller. Reliable and compact, they both answer your demands through innovative technologies and supreme energy efficiency without compromising on quality.

Automan AF/AC oil-lubricated piston compressors (1.5-8.1 kW)

Our range of Automan AF/AC piston compressors offers a compact, versatile and reliable source of compressed air when you need a small amount of compressed air for a variety of applications.

AF High grade aluminum piston compressors

Our range of AF aluminum piston compressors are all designed for mobility and ease of use. The compressor block is manufactured from high-grade aluminum alloy – the same material used in high-performance car engines. This ensures exceptional heat transfer capabilities and high tensile strength.

AC Belt drive Piston compressors

Designed with a slow-running compressor block for long service life, our AC belt drive cast iron piston compressors provides a solid source of compressed air with a high durability. We also provide aftercoolers and an automotive dry paper type air cleaner on the larger models, providing clean air for your needs.

LE oil-lubricated for single-stage compression

The single-stage oil-lubricated reciprocating compressor allows filtered air to enter both cylinders through the inlet valve. The piston is driven forward through the connection rod attached to the balanced crankshaft. Maximum operating pressure is 10 bar (145psi) and capacities range from 3.4 up to 31.7 l/s at 50 Hz, 8.3 to 79.8 cfm at 60 Hz. Air compressed in the cylinders leaves through the outlet valve when the pressure reaches 10 bar (145psi).

LT oil-lubricated for two-stage compression

The LT two-stage oil-lubricated reciprocating compressor allows filtered air to enter only one cylinder. This low pressure cylinder feeds the second (high pressure) cylinder that can operate at a maximum pressure of 15, 20 or 30 bar (218, 290 or 435 psi) and with the following capacities:

• 15 bar (218 psi):  from 3.1 to 11.7 l/s at 50 Hz, 7.6 to 23.1 cfm at 60 Hz.
• • 20 bar (290 psi):  from 2.1 to 18.0 l/s at 50 Hz, 5.7 to 44.3 cfm at 60 Hz.
• • 30 bar (435 psi):  from 2.5 to 17 l/s at 50 Hz, 6.6 to 41.7 cfm at 60 Hz.

Compression temperature is decreased between the two stages for increased compression efficiency.
